dispersion kneader

For Rubber Plastic & Chemical Industry Most Suitable Kneading Application For Dispersion Kneader: E. V. A. Rubber & TPR, Sole, Rubber Roller, Hoses Belts, Sponges, Vibration Insulator, Elastic Cord, Sealing Materials, Tire, Tapes, Master Batches, Pigment Ink, Automobile&Electric Rubber Parts, Chemical Industry Compounds. Feature for Dispersion Kneader: 1. An automatic temperature and time control system to provide a 100% mixing efect. 2. Easy to clean chamber and changing colors. 3. In 6 10 minutes/batch of output equivalent to 2 units of mixing Roller. 4. Pressurized and sealed mixing chamber to provide high mixing performance and prevented environmental pollution. Model X(S)N-3 X(S)N-10 X(S)N-20 X(S)N-35 X(S)N-55 X(S)N-75 X(S)N-110 Mixing capacity L 3 10 20 35 55 75 110 Main power KW 5.5 15 30 55 55/75 90/110 160/200 Brake Motor KW 0.37 0.75 1.5 2.2 3.0 4.0 5.5 Tilting Angle 110 110 110 140 140 140 140 Air compressor KW 1.5 2.2 3.0 5.5 7.5 10 10 Dust Collector HLL-10 HLL-10 HLL-10 HLL-10 HLL-15 HLL-20 HHL-30 Cooling Water MPA 0.2-0.4 0.2-0.4 0.2-0.4 0.3-0.4 0.3-0.4 0.3-0.4 0.3-0.4 Heating Steam MPA 0.5-0.8 0.5-0.8 0.5-0.8 0.5-0.8 0.5-0.8 0.5-0.8 0.5-0.8 Electric Heater KW 4 6 9 12 15 18 24 Machine Weight KG 1200 2300 4500 6500 7800 10500 14500 Overall Dimensions CM 196x970x182 220x135x215 250x148 x250 310x179 x271 342x214 X280 380x214 X318 440x276 X377
